Velux CFU Curved Glass Flat Roof Skylight Base & Top

he VELUX Fixed Flat Roof Skylight is designed for homes with flat or low-pitch roofs to transform and improve virtually any space with daylight.

The ISU top cover with CurveTech glass lets in more daylight, easily drains rainwater, and stands out externally as a modern addition to roof surfaces.

• 0° - 15° Roof pitch
• Deck-mounted
• Tempered glass top cover is virtually scratch-proof, providing a durable layer of protection
• Insulated PVC Frame
• CFU fixed base unit with laminated glass for added safety, sound control, and thermal protection

Innovative curve shape lets rainwater easily drain off, ensuring clearer sky views and more daylight, even on 0°-pitched roofs.

An ideal combination of insulating PVC frame and double-paned, low-energy inner glass ensures heat doesn’t escape, so your ideal indoor climate is maintained.

The curved glass shape provides natural drainage of rainwater – no need to regularly clean the surface – while toughened glass makes it virtually impervious to damage from the elements.

The values are obtained in accordance with NFRC procedures.

U-factor = 0.30
SHGC = 0.42
Visible Transmittance (Vt) = 0.58
